DOGUTRUCK D6811
DOGUTRUCK D6811 is a high-performance 580 g/m² PVC-coated textile from Doğusan, specifically designed for heavy-duty truck side curtains. Built on a high-tenacity 1100 dtex polyester base, it delivers 2800 N breaking strength and exceptional tear resistance. Its 1A-1A glossy lacquer finish provides excellent dirt resistance, while its 7-8 light fastness ensures UV durability. Fully compliant with EN 12641/2 and functional between -40°C and +70°C, it is the professional choice for reliable and flexible logistical protection.
DOGUTRUCK D6811: High-Performance Logistics Textile
DOGUTRUCK D6811, manufactured by Doğusan Technical Textile, is a high-durability PVC-coated textile specifically engineered for the logistics and transportation sector. With a total weight of 680 g/m² and a base fabric of high-tenacity 1100 dtex polyester, it offers an ideal balance of lightness and mechanical strength. It is designed to provide reliable protection for truck side curtains under various environmental conditions.
Key Technical Features
-
Mechanical Strength: Provides a robust breaking strength of 2800 N/5cm and a tear strength of 270 N in both warp and weft directions.
-
Surface and Coating: Features a PVC coating with a 1A-1A lacquering and a glossy embossed finish, ensuring a professional appearance and a dirt-repellent surface.
-
Environmental Resilience: Functions effectively in extreme temperatures ranging from -40°C to +70°C. It also exhibits superior color stability with a light fastness rating of 7-8.
-
Safety and Standards: Fully conforms to the EN 12641/2 industrial standard for truck side curtains. It also meets ISO 3795 fire behavior requirements with a burning rate of < 100 mm/min.
Primary Applications
-
Logistics: Primarily optimized for high-performance Truck Cover, Truck Roof and Truck Side Curtains.
-
Transportation: Suitable for vehicle covers and cargo protection systems requiring a lighter but strong material.
Product Specifications Summary
| Property | Specification |
| Product Name |
DOGUTRUCK D6811 |
| Total Weight |
680 g/m² |
| Base Fabric |
100% PES / 1100 dtex |
| Finish |
1A-1A Lacquered / Glossy |
| Temperature |
-40°C to +70°C |
| Industrial Standard |
EN 12641/2 |
Technical Data Sheet
|
|||||
| DOGUTRUCK D6811 | |||||
| Fabric | DIN ISO 2060:1994 | %100 PES / 1100 dtex | |||
| Total Weight | ISO 2286/2 :2016 | 680 g/m² | |||
| Coating | PVC | ||||
| Lacquering | 1A-1A | ||||
| Embossing | Glossy | ||||
| Breaking strength Warp | ISO 1421/1 : 2016 | 2800 N/5cm | |||
| Breaking strength Weft | ISO 1421/1 : 2016 | 2800 N/5cm | |||
| Tear strength Warp | DIN 53363 : 2003 | 270 N | |||
| Tear strength Weft | DIN 53363 : 2003 | 270 N | |||
| Adhesion | ISO 2411 : 2017 | 90 N/5cm | |||
| Temperature resistance | EN 1876/1 : 1998 | -40/+70°C | |||
| Light fastness (Except white and (half-)transparent) | ISO 105 B02 : 2014 | 7-8 | |||
| Fire behaviour | ISO 3795 : 1989 | < 100 mm/min | |||
| CONFORM | EN 12641/2 | ||||
| Application >> Truck / Side Curtain | |||||
Disclaimer: We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5. The information corresponds with our latest knowledge and is offered without liability.
Disclaimer
We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5 . The information corresponds with our latest knowledge and is offered without liability.
