DOGUTRUCK D105121
DOGUTRUCK D105121 is an ultra-heavy-duty 1050 g/m² PVC-coated textile from Doğusan, engineered for maximum durability in the logistics sector. Built on a high-tenacity 1100 dtex base, it delivers an exceptional 4000 N breaking strength and up to 600 N tear resistance. Its 2A-1A glossy lacquer finish provides premium dirt resistance and aesthetic appeal, while a 7-8 light fastness rating ensures long-term UV stability. Capable of operating between -40°C and +70°C, it is the professional choice for the most demanding train cover applications.
DOGUTRUCK D105121: Ultra-Heavy Duty Logistics Textile
DOGUTRUCK D105121, produced by Doğusan Technical Textile, is an ultra-high-performance PVC-coated textile designed for the most demanding logistics and transportation requirements. With an impressive weight of 1050 g/m² and a high-tenacity 1100 dtex polyester base, this product is built for maximum durability and structural resilience. It is engineered to withstand extreme mechanical stress and environmental exposure, making it a top-tier choice for heavy-duty vehicle protection.
Key Technical Features
-
Extreme Mechanical Strength: Delivers a massive breaking strength of 4000 N/5cm in both warp and weft directions, providing unparalleled structural integrity.
-
Superior Tear Resistance: Features a high tear resistance of 600 N (warp) and 500 N (weft), ensuring the fabric remains intact even under heavy impact or tension.
-
Advanced Surface Finish: Treated with a 2A-1A lacquering system and a glossy embossed finish, providing a highly professional look and a dirt-repellent surface.
-
Environmental Performance: Remains fully functional in extreme temperatures from -40°C to +70°C. It offers exceptional color stability with a light fastness rating of 7-8.
-
Adhesion and Stability: Boasts an adhesion force of 100 N/5cm, ensuring the PVC coating remains perfectly bonded to the base fabric under pressure.
Primary Applications
-
Logistics: Specifically optimized for Ultra-Heavy-Duty Train Cover.
-
Transportation: Ideal for large-scale vehicle covers and protective systems requiring maximum strength.
Product Specifications Summary
| Property | Specification |
| Product Name | DOGUTRUCK D105121 |
| Total Weight | 1050 g/m² |
| Base Fabric | 100% PES / 1100 dtex |
| Finish | 2A-1A Lacquered / Glossy |
| Temperature | -40°C to +70°C |
| Adhesion Force | 100 N/5cm |
Technical Data Sheet
|
|||||
| DOGUTRUCK D105121 | |||||
| Fabric | DIN ISO 2060:1994 | %100 PES / 1100 dtex | |||
| Total Weight | ISO 2286/2 :2016 | 1050 g/m² | |||
| Coating | PVC | ||||
| Lacquering | 2A-1A | ||||
| Embossing | Glossy | ||||
| Breaking strength Warp | ISO 1421/1 : 2016 | 4000 N/5cm | |||
| Breaking strength Weft | ISO 1421/1 : 2016 | 4000 N/5cm | |||
| Tear strength Warp | DIN 53363 : 2003 | 600 N | |||
| Tear strength Weft | DIN 53363 : 2003 | 500 N | |||
| Adhesion | ISO 2411 : 2017 | 100 N/5cm | |||
| Temperature resistance | EN 1876/1 : 1998 | -40/+70°C | |||
| Light fastness (Except white and (half-)transparent) | ISO 105 B02 : 2014 | 7-8 | |||
| Fire behaviour_FR /
Fire behaviour_DE / Reaction to fire_EU / |
NF P 92-507:2004 DIN 4102-1 : 1998 EN 13501-1 : 2018 | M2
B1 B-s2,d0 |
|||
| CONFORM | EN 12641/2 | ||||
| Application >> Train Cover | |||||
Disclaimer : We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5 . The information corresponds with our latest knowledge and is offered without liability.
Disclaimer
We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5 . The information corresponds with our latest knowledge and is offered without liability.
