DOGUVENT D68100 MATT NP AS
DOGUVENT D68100 MATT NP AS is a heavy-duty 680 g/m² PVC-coated textile from Doğusan, engineered with Antistatic properties for safe, large-scale industrial ventilation. Built on a high-tenacity 1100 dtex polyester base, it provides an exceptional 3000 N breaking strength and high 350 N tear resistance, offering superior durability. Its unlacquered, dull (matt) finish provides a non-reflective, highly utilitarian surface. Operating securely between -40°C and +70°C, this waterproof and static-dissipative material is the ultimate high-strength solution for heavy-duty flexible ducts and protective covers in sensitive, demanding environments.
DOGUVENT D68100 MATT NP AS: Heavy-Duty Antistatic Ventilation Textile
DOGUVENT D68100 MATT NP AS, manufactured by Doğusan Technical Textile, is a highly robust, specialized PVC-coated fabric engineered for demanding industrial ventilation and protective applications where static electricity control is critical. With a heavier total weight of 680 g/m² and a high-tenacity 1100 dtex polyester base, it provides superior mechanical strength and durability. Its core features are its Antistatic formulation and its unlacquered Dull (Matt) finish, making it uniquely suited for heavy-duty, non-reflective environments that require stringent safety protocols.
Key Technical Features
-
Antistatic Properties: Specifically formulated to safely dissipate static electricity, preventing dangerous build-ups in heavy industrial, mining, or chemical ventilation systems.
-
Exceptional Mechanical Strength: Delivers an impressive breaking strength of 3000 N/5cm in both warp and weft directions, ensuring maximum structural integrity for large-scale flexible ducts and tensioned covers.
-
High Tear Resistance: Features an elevated tear strength of 350 N for both warp and weft, safeguarding the material against harsh mechanical impacts and demanding operational wear.
-
Matte Surface Profile: Features a Dull (Matt) embossed finish without an additional lacquer coating, providing a completely non-reflective, highly utilitarian surface.
-
Extreme Weather Performance: Engineered to function flawlessly in temperatures ranging from -40°C to +70°C, ensuring safe operation across extreme industrial climates.
Primary Applications
-
Heavy Industrial Ventilation: Specifically optimized for large-diameter, flexible ventilation ducts and mining tubes where high pressure, high strength, and static dissipation are required.
-
Static-Sensitive Structural Covers: Ideal for heavy-duty equipment covers and enclosures in chemical plants or hazardous environments where antistatic properties are mandated.
Product Specifications Summary
| Property | Specification |
| Product Name | DOGUVENT D68100 MATT NP AS |
| Total Weight | 680 g/m² |
| Base Fabric | 100% PES / 1100 dtex |
| Finish | Dull (Matt) / Unlacquered |
| Special Feature | ANTISTATIC |
| Temperature Range | -40°C to +70°C |
Technical Data Sheet
|
|||||
| DOGUVENT D68100 MATT NP AS | |||||
| Fabric | DIN ISO 2060:1994 | %100 PES / 1100 dtex | |||
| Total Weight | ISO 2286/2 :2016 | 680 g/m² | |||
| Coating | PVC | ||||
| Characteristics | ANTISTATIC | ||||
| Lacquering | - | ||||
| Embossing | DULL | ||||
| Breaking strength Warp | ISO 1421/1 : 2016 | 3000 N/5cm | |||
| Breaking strength Weft | ISO 1421/1 : 2016 | 3000 N/5cm | |||
| Tear strength Warp | DIN 53363 : 2003 | 350 N | |||
| Tear strength Weft | DIN 53363 : 2003 | 350 N | |||
| Temperature resistance | EN 1876/1 : 1998 | -40/+70°C | |||
| Light fastness (Except white and (half-)transparent) | ISO 105 B02 : 2014 | 6 | |||
| Fire behaviour | DIN 4102 | B2 | |||
| surface resistance | DIN 54345 T1:1992 | < 1. 10E09 Ohm | |||
| Application >> VENTILATION TUBES | |||||
Disclaimer : We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5 . The information corresponds with our latest knowledge and is offered without liability.
Disclaimer
We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5 . The information corresponds with our latest knowledge and is offered without liability.
