DOGUTRUCK D6300 matt
DOGUTRUCK D6300 MATT is a professional-grade 630 g/m² PVC-coated textile from Doğusan, optimized for the logistics industry. Utilizing a high-tenacity 1100 dtex base, it provides a reliable 2500 N breaking strength and 220 N tear resistance. Its distinctive Matt finish offers a sophisticated, non-reflective appearance without compromising on performance. With a high 7-8 light fastness rating and a temperature tolerance from -40°C to +70°C, it provides durable, waterproof, and aesthetic protection for truck curtains and heavy-duty vehicle covers.
DOGUTRUCK D6300 MATT: Sophisticated Durability for Modern Logistics
DOGUTRUCK D6300 MATT, manufactured by Doğusan Technical Textile, is a high-quality PVC-coated fabric designed for the transportation sector. It perfectly balances a weight of 630 g/m² with a high-tenacity 1100 dtex polyester base. Its standout feature is the specialized Matt finish, which provides a modern, non-reflective aesthetic while maintaining the rugged durability required for truck side curtains and protective covers. This material is engineered to offer long-lasting protection against mechanical stress and harsh environmental conditions.
Key Technical Features
-
Precision Mechanical Strength: Delivers a consistent breaking strength of 2500 N/5cm and a tear resistance of 220 N in both warp and weft directions.
-
Premium Matt Surface: Features a specialized Matt embossing that reduces glare and provides a professional, low-maintenance surface.
-
Superior Color Integrity: Boasts an exceptional light fastness rating of 7-8 (ISO 105 B02:2014), ensuring that the fabric retains its color even under prolonged sun exposure.
-
Extreme Weather Performance: Fully functional in a wide temperature range from -40°C to +70°C, maintaining flexibility in freezing cold and structural stability in intense heat.
-
Safety Compliance: Meets ISO 3795:1989 fire behavior standards with a controlled burning rate of < 100 mm/min.
Primary Applications
-
Logistics: Ideal for Contaiers and Trucks, vehicle covers where a matte, non-reflective finish is preferred.
-
Transportation: Used for protective cargo systems and high-durability vehicle tarpaulins.
-
Industrial: Suitable for outdoor protective systems requiring a balance of lightweight handling and strength.
Product Specifications Summary
| Property | Specification |
| Product Name | DOGUTRUCK D6300 MATT |
| Total Weight | 630 g/m² |
| Base Fabric | 100% PES / 1100 dtex |
| Finish | Matt (Dull) Emboss |
| Adhesion Force | 70 N/5cm |
| Temperature Range | -40°C to +70°C |
Technical Data Sheet
|
|||||
| DOGUTRUCK D6300 matt | |||||
| Fabric | DIN ISO 2060:1994 | %100 PES / 1100 dtex | |||
| Total Weight | ISO 2286/2 :2016 | 630 g/m² | |||
| Coating | PVC | ||||
| Lacquering | - | ||||
| Embossing | MATT | ||||
| Breaking strength Warp | ISO 1421/1 : 2016 | 2500 N/5cm | |||
| Breaking strength Weft | ISO 1421/1 : 2016 | 2500 N/5cm | |||
| Tear strength Warp | DIN 53363 : 2003 | 220 N | |||
| Tear strength Weft | DIN 53363 : 2003 | 220 N | |||
| Adhesion | ISO 2411 : 2017 | 70 N/5cm | |||
| Temperature resistance | EN 1876/1 : 1998 | -40/+70°C | |||
| Light fastness (Except white and (half-)transparent) | ISO 105 B02 : 2014 | 6-7 | |||
| Fire behaviour | ISO 3795 : 1989 | < 100 mm/min | |||
| CONFORM | EN 12641/2 | ||||
| Application >> Top Container / Truck / General Application | |||||
Disclaimer : We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5 . The information corresponds with our latest knowledge and is offered without liability.
Disclaimer
We reserve modifications of the mentioned values for technical reasons.Values without tolerance statements are values with a tolerance of ± %5 . The information corresponds with our latest knowledge and is offered without liability.
